8" ULTIMAX II DVC SUBWOOFER - DAYTON AUDIO

    $349.00

- +
BUY NOW
  • Order Code: UMII8-22
  • Availability: Pre-Order
    ETA: 20-08-2025

    • DUAL 2 OHM VOICE COIL

    The Dayton Audio Ultimax II 8” DVC subwoofer features a carbon fibre cone and dual 2Ω voice coils. It offers high SPL, ultra-low bass extension, minimal distortion, and performs well even in small sealed enclosures as small as 0.5 cubic feet. It is a powerful choice for home theatre and car audio systems.

  • The Dayton Audio Ultimax II 8" subwoofer has a carbon fibre cone and dual 2Ω voice coils. It delivers a powerful bass response that can handle up to 400W RMS and 800W peak power, making it an ideal choice for home theatre setups and car audio systems. The subwoofer features a rigid cast aluminium frame, dual spiders, a 2½" flat wound voice coil, dual shorting rings, extensive venting, and an FEA-optimised motor. It delivers high SPL, ultra-low bass extension, and minimal distortion. The UMII8-22 is versatile, capable of performing in small sealed enclosures as small as 0.5 cubic feet, and with a vented design, it will deliver an F3 under 30Hz from enclosures as small as 1 cubic foot, offering impressive output capabilities.

    • Features large aluminium short...

    • Read / Show More
    Related Products for 8

    Related Products : View Product Group Page

    8

    Found in Category : Speaker Drivers

    Product Specs for 8" ULTIMAX II DVC SUBWOOFER - DAYTON AUDIO

    Description Dayton Audio Ultimax II 8" DVC Subwoofer 2 Ohm Per Coil
    Manufacturer Dayton Audio
    Cms 0.148mm/N
    Coil 63.5mmØ
    Depth 135mm
    Diam. 214mmØ
    Fs 46Hz
    Hole 185mmØ
    Impedance 2x2Ω Re 3.9Ω
    Impedance (Ohm) 2+2 ohm
    Inch 8
    Le 0.75mH
    Mms 82g
    Power 400Wrms
    Power (RMS) 200+ Watt
    Price Type each
    Prms 400W
    Qes 0.99
    Qms 3.1
    Qts 0.75
    QTY 1
    Re 3.9Ω
    Sd 200cm²
    Sens. 84.1dB
    Series Ultimax Series
    Size 8'
    Type DVC subwoofer
    Vas 8.4L
    Zn 2x 2Ω
