SB ACOUSTICS 6" FULL RANGE - FRPC

    $65.00

- +
BUY NOW
  • Order Code: SB16FRPC25-7
  • Availability: In Stock

    • PAPER CONE WITH WHIZZER EXTENDER & PHASE PLUG

  • The SB Acoustics 6" SB16FRPC25-7 full-range speaker features a proprietary paper cone with natural fibres, lightweight foam surround, and optimised whizzer cone for smooth high-frequency extension. Its vented spider, reinforced plastic chassis, and extended copper sleeve ensure controlled radiation, durability, and enhanced performance.

    • Proprietary cone material with natural fibres made in-house.
    • Light weight foam surround.
    • Optimised whizzer cone for smooth high frequency extension.
    • Phase plug for controlled radiation.
    • Vented spider with flexibility control.
    • Optimised motor system.
    • Vented reinforced plastic chassis.
    • Non-conductive coil former.
    • Long life lead wires.
    • Extended ...

    • Read / Show More
    Related Products for SB ACOUSTICS 6

    Related Products : View Product Group Page

    SB ACOUSTICS 6

    Found in Category : Speaker Drivers

    Product Specs for SB ACOUSTICS 6" FULL RANGE - FRPC

    Description 25mm Voice coil, paper cone, lightweight foam surround, ferrite motor, round injection chassis, 6" full range driver
    Bl 5.4Tm
    Cms 1.33mm/N
    Coil 25.4mmØ
    Depth 73.2mm
    eBook

    Link to eBook
    Flux (lm) 1.05T
    Fs 44Hz
    Hole 144.5mmØ
    Hole Cutout 144.5mmØ
    Impedance 7Ω Re 5.2Ω
    Impedance (Ohm) 7 ohm
    Inch 6
    Le 0.22mH
    Link SB Acoustics SB16FRPC25-7
    Mag. 0.29kg
    Manufacturer SB Acoustics
    Materials Natural fibre
    Mms 9.8g
    Note. Data is correct to stock at time of printing, however SBA are constantly improving their stock and data may change without notice. For the latest datasheets, please see www.sbacoustics.com
    Power 30Wrms
    Power (RMS) 0-50 Watt
    Price Type each
    Prms 30W
    Qes 0.48
    Qms 9
    Qts 0.46
    QTY 1
    Re 5.2Ω
    Rms 0.3kg/s
    Sd 128cm²
    Sens. 91dB
    Series FRPC
    Size 6'
    Type Full range
    Vas 31L
    Width 176mmØ
    Zn 7Ω
    DescriptionFileSize
    Datasheet SB16FRPC25-7.pdf 673 KB
    SB Acousti SB-Acoustics-Catalogue.pdf 26322 KB
