Product Specs for MICRO PARTS LIST
| Description |
0.75" Tweeter Dome Tweeter 4 ohm |
| Type |
Tweeter |
| Size |
0.75' |
| Price Type |
each |
| Power |
30Wrms |
| Colour |
textile |
| QTY |
1 |
| Series |
Dome Tweeter |
| Impedance (Ohm) |
4 ohm |
| Sold As |
Single |
| Zn |
4Ω |
| Mag. |
0.13kg |
| Xmax |
1.2mm |
| Qes |
1.5 |
| Page |
16 |
| Sd |
3.8cm² |
| Power (RMS) |
0-50 Watt |
| Fs |
980Hz |
| Note. |
Data is correct to stock at time of printing, however SBA are constantly improving their stock and data may change without notice. For the latest datasheets, please see www.sbacoustics.com |
| Impedance |
4Ω Re 3.4Ω |
| Sens. |
88.5dB |
| Diam. |
Ref |
| Inch |
0.75 |
| Coil |
19.1mmØ |
| eBook |
Link to eBook |
| Bl |
1.75Tm |
| Prms |
30W |
| Qms |
6.45 |
| Width |
88mmØ |
| Manufacturer |
SB Acoustics |
| Flux (lm) |
1.24T |
| Mms |
0.22g |
| Wagner eBook |
03-164, 03-219 |
| Le |
0.07mH |
| Qts |
1.22 |
| Link |
SB Acoustics SB19ST-C000-4 |
| Depth |
21mm |
| Re |
3.4Ω |
| Materials |
Textile |
